Unparalleled Power and Versatility
With a robust 37 kW engine, the Mini Skid Wheel Loader LC-W35 can effortlessly handle an operating load of up to 500 kg, ensuring that no task is too demanding. Whether you’re moving earth, gravel, or construction materials, this loader has the muscle to get the job done.
Swift and Precise Maneuvering
Navigate even the most challenging terrain with ease. The Mini Skid Wheel Loader LC-W35 boasts a top speed of 10 km/h, making it one of the fastest in its class. Its agile wheelbase of 897 mm and a front turning radius of just 1098 mm without the bucket ensure you can tackle tight spaces and sharp corners effortlessly
Enhanced Productivity
The Mini Skid Wheel Loader LC-W35 offers a rated flux of 60 L/min, guaranteeing rapid and efficient hydraulic operations. Its self-weight bucket of 2300 kg and a generous bucket capacity of 0.3 m³ enable you to move more material in less time, ultimately boosting your productivity on the job site.
Operator Comfort and Safety
Your comfort and safety are our priorities. The Mini Skid Wheel Loader LC-W35 features a spacious cab with an overall height of 2000 mm and an ergonomic design, providing the operator with an unobstructed view and reducing operator fatigue. With an angle of departure of 20° and a ground clearance of 140 mm, you can confidently traverse rough terrains while maintaining stability.
Durable and Built to Last
Crafted with high-quality materials and precision engineering, the Mini Skid Wheel Loader LC-W35 is built to endure the toughest conditions. Its durable 8.5-15 track tires, 1400 mm bucket width, and 2950 mm overall length with the bucket ensure it can handle a wide range of tasks without breaking a sweat.
Effortless Dumping and Control
The Mini Skid Wheel Loader LC-W35 features a 40° dumping angle at maximum height, allowing you to deposit materials exactly where you need them. With a dumping height of 2050 mm and a dumping reach of 790 mm, you have maximum control over your load.
Upgrade your construction and material handling operations with the Mini Skid Wheel Loader LC-W35. With its impressive specifications and unbeatable performance, it’s the smart choice for contractors and professionals who demand the best. Order now and experience the future of compact construction equipment!
| Model | LC-W35 |
| Operating load（kg） | 500 |
| Max speed（km/h） | 10 |
| Rated flux(L/min) | 60 |
| High Flow Flux(L/min) | / |
| Tire(track)model | 8.5-15 |
| Rated power(kw) | 37 |
| Fuel tank capacity(L) | 60 |
| Self-weight bucket(kg) | 2300 |
| Bucket capacity(m³) | 0.3 |
| Overall operating height（mm） | 3300 |
| Height to bucket hinge pin（mm） | 2725 |
| Height to top of cab（mm） | 2000 |
| Height to bottom of level bucket（mm） | 2558 |
| Without bucket lengeh(mm) | 2300 |
| Overall length with bucket(mm) | 2950 |
| Dumping angle at maximum height(°) | 40 |
| Dumping height(mm) | 2050 |
| Dumping reach(mm) | 790 |
| Rollback of bucket on ground(°) | 30 |
| Rollback of bucket at full height(°) | 104 |
| Wheelbase(mm) | 897 |
| Ground clearance(mm) | 140 |
| Angle of departure（°） | 20 |
| Front turning radius without bucket(mm) | 1098 |
| Front turning radius(mm) | 1760 |
| Rear tuning radius(mm) | 1296 |
| Rear axle to bumper(mm) | 964 |
| Tread width(mm) | 1080 |
| Width(mm) | 1350 |
| Bucket width(mm) | 1400 |
